STARTECH .com DAS Array - 2 x SSD Supported

Retail price: $118.79
$117.50
(Includes GST) You save: $1.29 (1%) Save 1%
25S22M2NGFFR
Available
+
Add to favourites

Description

Install two M.2 NGFF SSDs into a 2.5" bay to create high-performance storage with configurable RAID. Boost your system performance by enhancing the capacity, speed and security of your data storage. This two-drive M.2 to SATA adapter lets you install two M.2 solid-state drives in a single 2.5" drive bay and configure a powerful RAID array.

Build a RAID array to enhance system performance

The dual M.2 to SATA adapter supports multiple RAID modes (RAID 0, 1, BIG) helping you to achieve greater SSD capacity or data redundancy, depending on your selected RAID mode. The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another.

Maximize file transfer speeds

The dual SSD adapter lets you utilize the full potential of your SATA III controller. Using M.2 SSDs in place of a platter drive reduces your data transfer bottlenecks and gives you file transfer speeds of up to 6 Gbps. M.2 SSDs also save you money by reducing your power consumption over regular platter drives.

The M.2 NGFF SATA RAID adapter also provides TRIM support to enhance the stability and performance of your M.2 NGFF SSDs.

Get dependable drive protection

The M.2 to SATA adapter features an enclosed housing that helps protect your NGFF (Next Generation Form Factor) SSD. The added protection gives you peace of mind when you are using your M.2 drives in applications that require an added level of durability such as hot-swap drive bays, or external SATA docking stations.

The 25S22M2NGFFR is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Specifications

General Information

Manufacturer:
StarTech.com
Manufacturer Website Address:
http://www.startech.com/au
Brand Name:
StarTech.com
Product Name:
Dual M.2 NGFF SATA Adapter With RAID
Packaged Quantity:
1
Product Type:
DAS Array

Storage

Number of Solid State Drive Supported:
2

Controllers

Controller Type:
  • Serial ATA/600
RAID Levels:
  • 0, 1, Concatenation, JBOD

Interfaces/Ports

Drive Interface:
M.2
Host Interface:
  • SATA/600

Physical Characteristics

Form Factor:
Internal
Height:
7.6 mm
Width:
68.6 mm
Depth:
99.1 mm
Weight (Approximate):
53.9 g
