ZEBRA ZT230 Direct Thermal Printer - Monochrome - Label Print

ZT23042-D0P100FZ

This product has been discontinued by the manufacturer

Please visit

ZEBRA Label/Receipt Printers

for alternative options.

Description

Zebra incorporated extensive customer feedback, as well as the legacy of our industry leading Stripe and S4M printers, to create the new ZT200 Series family of printers with elegant space-saving design, effortless setup, intuitive user operation, and ease of service and maintenance.

Simplified Operation and Outstanding Value

The ZT200 series is designed to simplify and shorten servicing and consumable replacement time. The easy tool-less platen and print head removal makes it easy for operators to maintain the printer. The side loading supplies path enables simplified media and ribbon insertion and color coded media path clearly directs media and ribbon threading.

Compact footprint fits where space is at a premium

The ZT200 Series printer's compact design, when closed and opened, fits easily in constrained work areas. The ergonomic Bi-fold door requires only 4" (102mm) of door swing room. This reduces the printer height making it ideal for placement under a shelf or against another item.

Versatility at an economical price

Both of the ZT200 series printers feature the same attractive styling, are built on a common platform and share many of the same internal components. The ZT200 has a 300m ribbon capacity and the ZT230 can accommodate a 450m ribbon. The ZT200 handles a variety of media types and the optional peel, cutter and line take up offer additional flexibility for a variety of applications.

Specifications

General Information

Manufacturer:
Zebra Technologies Corporation
Manufacturer Website Address:
http://www.zebra.com/ap/en.html
Brand Name:
Zebra
Product Series:
ZT200
Product Model:
ZT230
Product Name:
ZT230 Industrial Printer
Product Type:
Direct Thermal Printer

Technical Information

Recommended Use:
Label Print
Maximum Mono Print Speed:
152 mm/s
Maximum Print Resolution:
203 dpi
Maximum Print Width:
103.89 mm (4.09")

Memory

Standard Memory:
  • 128 MB

Interfaces/Ports

Parallel Port:
Yes
Serial Port:
Yes
USB:
Yes

Media Types & Handling

Media Type:
  • Notch
  • Continuous Label
  • Black Mark
  • Die-cut Label
Maximum Roll Diameter:
203.20 mm
Maximum Label Width:
114.30 mm

Power Description

Power Source:
  • AC Supply

Physical Characteristics

Height:
279.4 mm
Width:
238.8 mm
Depth:
431.8 mm
Weight (Approximate):
7.71 kg
