ZEBRA TLP 2824 Plus Thermal Transfer Printer - Monochrome - Desktop - Label Print

282P-1011P2-040

This product has been discontinued by the manufacturer

Please visit

ZEBRA Label/Receipt Printers

for alternative options.

Description

The ultra-compact TLP 2824 Plus™ bar code label printer, for print widths up to 2.2 inches/56 mm, brings powerful performance to applications requiring both direct thermal and thermal transfer printing. It includes a 32-bit RISC processor for faster formatting and first label out, an auto-sensing serial port, and co-resident EPL and ZPL programming languages. Available options include additional memory, 10/100 Ethernet, label peeler, and receipt/label cutter.

Its ease of use-including Zebra Setup Utilities software for simple setup, OpenACCESS™ design and clear media window for simple media loading and monitoring, and an instant reset button-results in increased workplace efficiency. Offering flexible connectivity and options, the TLP 2824 Plus fits easily into a variety of applications.

Specifications

General Information

Manufacturer:
Zebra Technologies Corporation
Manufacturer Website Address:
http://www.zebra.com
Brand Name:
Zebra
Product Model:
TLP 2824 Plus
Product Name:
TLP 2824 Plus Thermal Label Printer
Product Type:
Thermal Transfer Printer

Technical Information

Recommended Use:
Label Print
Print Colour:
  • Monochrome
Maximum Mono Print Speed:
101.60 mm/s
Maximum Print Resolution:
203 dpi
Maximum Print Width:
55.88 mm (2.20")

Memory

Standard Memory:
  • 8 MB

Interfaces/Ports

Serial Port:
Yes
USB:
Yes

Media Types & Handling

Media Type:
  • Black Bar
  • Continuous Form
  • Continuous Receipt
  • Die-cut Label
  • Fanfold
  • Gap
  • Notch
  • Notched
  • Perforated Label
  • Receipt
  • Roll Fed
  • Tag
  • Tag Stock
Maximum Roll Diameter:
127 mm
Maximum Label Width:
59.94 mm
Maximum Label Length:
990.60 mm

Physical Characteristics

Form Factor:
Desktop
Height:
177.8 mm
Width:
134.6 mm
Depth:
241.3 mm

Miscellaneous

Package Contents:
  • TLP 2824 Plus Thermal Label Printer
  • Software Drivers CD
Platform Supported:
  • PC

Warranty

Standard Warranty:
1 Year
