ZEBRA Symbol LS4208 Handheld Barcode Scanner - Cable Connectivity - Black
This product has been discontinued by the manufacturer
Please visit
ZEBRA Barcode Scannersfor alternative options.
Description
With Symbol's LS4208 handheld laser Bar Code Reader, user is able to effortlessly speed throughput, even with bar codes in poor condition. Wherever need to quickly capture and process data such as at the retail checkout counter, in pharmacies and hospitals, and in light warehouse environments this ergonomically designed scanner helps to increase accuracy, improve productivity, cut maintenance costs and reduce the risk of downtime.
Specifications
General Information
Manufacturer:
Zebra Technologies Corporation
Manufacturer Website Address:
http://www.zebra.com
Brand Name:
Zebra
Product Family:
Symbol
Product Model:
LS4208
Product Name:
Symbol LS 4208 Bar Code Reader
Product Type:
Handheld Barcode Scanner
Technical Information
Connectivity Technology:
- Cable
Bar Code Dimension:
- 2D
- 1D
Bar Code Symbology Supported:UPC/EAN Supplementals Code 39 Code 39 Full ASCII Trioptic Code 39 RSS Variants UCC/EAN 128 Code 128 Code 128 Full ASCII Code 93 Codabar (NW1) Interleaved 2 of 5 Discrete 2 of 5 MSI Code ll IATA Bookland EAN Code 32 PDF 417 Micro PDF Composite Codes
Light Source:
- Laser
Maximum Scan Resolution:
0.13 mm
Depth of Field:
- 0 nm - 736.60 mm@0.51 mm - Code 39
- 0 nm - 482.60 mm@0.33 mm - 100% UPC/EAN
- 0 nm - 355.60 mm@0.25 mm - Code 39
- 38.10 mm - 139.70 mm@0.13 mm - Code 39
Scan Pattern:
2D Raster
Interfaces/Ports
Host Interface:
- Multi-interface
Power Description
Input Voltage:
- 5 V DC
Physical Characteristics
Colour:
- Black
Height:
170.2 mm
Width:
68.6 mm
Depth:
94 mm
Weight (Approximate):
181.4 g
Miscellaneous
Additional Information:
- Supported Interfaces:
- Serial
- IBM 468X/469X
- Keyboard Wedge
- USB
- Wand Emulation
Certifications & Standards:
Electrical safety:UL1950 CSA C22.2 No. 950 EN60950/IEC950 Laser safety:CDRH Class II IEC Class 2 EMI/RFI:FCC Part 15 Class B ICES-003 Class B European Union EMC Directive Australian SMA
Warranty
Standard Warranty:
5 Year
