Netgear ProSafe WN370 IEEE 802.11n 300 Mbps Wireless Access Point - ISM Band

WN370-10000S

This product has been discontinued by the manufacturer

Please visit

NETGEAR Wireless Access Points/Bridges

for alternative options.

Description

The WN370 Wall Mount Access Point is designed specifically for in-room coverage for wired and wireless access for small and medium hotels and education dormitories. The WN370 has a sleek, elegant, and compact design that allows the AP to be deployed in an inconspicuous manner and can be installed quickly by non-technical personnel. The WN370 is powered with PoE with 1Gbps uplink and 4 (100 Mbps) Ethernet data ports, plus additional voice port for connectivity to digital phones. The WN370 is centrally managed by an enterprise class wireless controller with automatic RF and power tuning with guest captive portal and comprehensive wireless security.

Specifications

General Information

Manufacturer:
Netgear, Inc
Manufacturer Website Address:
http://www.netgear.com/
Brand Name:
Netgear
Product Family:
ProSafe
Product Model:
WN370
Product Name:
ProSafe WN370 Wall Mount Access Point
Product Type:
Wireless Access Point

Technical Information

Wi-Fi Standard:
  • IEEE 802.11n
ISM Band:
Yes
UNII Band:
No
ISM Maximum Frequency:
2.40 GHz
Antenna Gain:
  • 3 dBi
Wireless Transmission Speed:
300 MBps
Wireless Security:
    • WEP
    • WPA-PSK
    • WPA-TKIP
    • WPA2
    • AES
    • IEEE 802.1x
    • MAC ACL
    • Rogue AP Detection
Features:
  • Quality of Service (QoS)
  • MIMO Technology

Interfaces/Ports

Ethernet Port:
Yes
Fast Ethernet Port:
Yes
Gigabit Ethernet Port:
Yes
10Gigabit Ethernet Port:
No
Number of Network (RJ-45) Ports:
5
Network (RJ-11):
No
PoE Port:
No
VGA:
No
HDMI:
No
Audio Line Out:
No
Serial Port:
No
USB:
No
Powerline:
No
Management Port:
No

Management & Protocols

Management:
    • Web-based Management
    • Command Line Interface (CLI)
    • SNMP v1, v2
    • MIB
    • VLAN

Power Description

Power Source:
  • PoE

Physical Characteristics

Form Factor:
Wall Mountable
Height:
29.5 mm
Width:
96.5 mm
Depth:
138.7 mm
Weight (Approximate):
218 g

Miscellaneous

Package Contents:
  • ProSafe WN370 Wall Mount Access Point
  • Wall-Mount Kit
  • Installation Guide
  • Warranty/Support Information Card
Certifications & Standards:
Safety Certification:
  • UL/cUL
  • CE (EN60950-1)
Countries Certification (Minimum Set):
  • FCC
  • IC
  • CE
  • EN55022/24
  • EN301489
  • EN301489-17
  • EN30328
  • EN60950
  • C-Tick
  • A-Tick
  • SRRC
IEEE Standards:
  • 802.3
  • 802.3u
  • 802.3ab
  • 802.11b
  • 802.11g
  • 802.11n

Warranty

Standard Warranty:
