CISCO Aironet 2504 Wireless LAN Controller

CISCO Aironet 2504 Wireless LAN Controller
AIR-CT2504-15-K9

This product has been discontinued by the manufacturer

Please visit

CISCO Wireless Access Points/Bridges

for alternative options.

Description

The Cisco 2500 Series Wireless Controller enables systemwide wireless functions in small to medium-sized enterprises and branch offices. Designed for 802.11n performance, Cisco 2500 Series Wireless Controllers are entry-level controllers that provide real-time communication between Cisco Aironet access points to simplify the deployment and operation of wireless networks As a component of the Cisco Unified Wireless Network, this controller delivers centralized security policies, wireless intrusion prevention system (wIPS) capabilities, award-winning RF management and quality of service (QoS) for voice and video. Delivering 802.11n performance and scalability the 2500 Series provides low total cost of ownership and flexibility to scale as network requirements grow.

Specifications

General Information

Manufacturer:
Cisco Systems, Inc
Manufacturer Website Address:
http://www.cisco.com/c/en_au
Brand Name:
Cisco
Product Family:
Aironet
Product Series:
2500
Product Model:
2504
Product Name:
Aironet 2504 Wireless LAN Controller
Product Type:
Wireless LAN Controller

Technical Information

ISM Band:
No
UNII Band:
No
Wireless Security:
    • IEEE 802.1x
    • AES
    • EAP-TLS
    • DES
    • 3DES
    • MD5
    • SHA-1
    • IPsec
    • AAA
Features:
  • Quality of Service (QoS)

Interfaces/Ports

Ethernet Port:
Yes
Fast Ethernet Port:
Yes
Gigabit Ethernet Port:
Yes
10Gigabit Ethernet Port:
No
Number of Network (RJ-45) Ports:
4
PoE Port:
No
VGA:
No
Serial Port:
No
USB:
No
Powerline:
No
Management Port:
Yes

Management & Protocols

Management:
    • DHCP
    • SNMP v1, v2c, v3
    • TACACS
    • Web-Based Management
    • Telnet
    • MIB/MIB II
    • Syslog
    • Command-line interface

Power Description

Input Voltage:
  • 110 V AC
  • 220 V AC
Power Source:
  • Power Supply

Physical Characteristics

Compatible Rack Unit:
1U
Form Factor:
Rack-mountable
Height:
43.9 mm
Width:
203.2 mm
Depth:
171.5 mm
Weight (Approximate):
1.59 kg

Miscellaneous

Certifications & Standards:
IEEE Standards:
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.1x
Safety:
  • UL 60950-1, 2nd Edition
  • EN 60950:2005
EMI and susceptibility (Class B):
  • U.S.: FCC Part 15.107 and 15.109
  • Canada: ICES-003
  • Japan: VCCI
  • Europe: EN 55022, EN 55024

Warranty

Standard Warranty:
90 Day
