CISCO 8510 Wireless LAN Controller

CISCO 8510 Wireless LAN Controller
AIR-CT8510-300-K9

This product has been discontinued by the manufacturer

Please visit

CISCO Wireless Access Points/Bridges

for alternative options.

Description

The Cisco 8500 Series Controller provides centralized control, management, and troubleshooting for high-scale deployments in service provider and large campus deployments. The 8500 series provides flexibility to support multiple architectures in the same controller - centralized controller switched for campus, Cisco FlexConnect™ for lean branches managed over the WAN as well as mesh support for deployments where full Ethernet cabling is unavailable.

Cisco 8500 Series Controllers automate wireless configuration and management functions and allow network managers to have the visibility and control needed to cost-effectively manage, secure, and optimize the performance of their branch networks. As a component of the Cisco Unified Wireless Network, this controller provides real-time communications between Cisco Aironet® access points, the Cisco Prime™ Infrastructure, and the Cisco Mobility Services Engine, and is interoperable with other Cisco controllers.

Specifications

General Information

Manufacturer:
Cisco Systems, Inc
Manufacturer Website Address:
http://www.cisco.com/c/en_au
Brand Name:
Cisco
Product Series:
8500
Product Model:
8510
Product Name:
8500 Series Controller for up to 300 Cisco Access Points
Product Type:
Wireless LAN Controller

Technical Information

ISM Band:
No
UNII Band:
No

Interfaces/Ports

Ethernet Port:
Yes
Fast Ethernet Port:
Yes
Gigabit Ethernet Port:
Yes
10Gigabit Ethernet Port:
Yes
Number of Network (RJ-45) Ports:
1
Network (RJ-11):
No
PoE Port:
No
Powerline:
No

I/O Expansions

Expansion Slots:
  • 2 x SFP+

Management & Protocols

Management:
    • SNMP v1, v2c, v3
    • Telnet
    • MIB
    • Syslog
    • Web-based (HTTP/HTTPS)
    • Cisco Wireless Control System (WCS)
    • CLI

Physical Characteristics

Compatible Rack Unit:
1U
Form Factor:
Rack-mountable
Height:
42.9 mm
Width:
439.4 mm
Depth:
711.2 mm
Weight (Approximate):
15.92 kg

Miscellaneous

Certifications & Standards:
Safety:
  • UL 60950-1:2003
  • EN 60950:2000
  • EMI and susceptibility (Class A):
  • U.S.: FCC Part 15.107 and 15.109
  • Canada: ICES-003
  • Japan: VCCI
  • Europe: EN 55022, EN 55024

Warranty

Standard Warranty:
90 Day
