HPE HP KVM Switchbox
Description
Looking for a simple and intuitive solution that allows you to access and manage servers in your data center? HP KVM Analog Console Switches allow you to view and manage up to 256 rackmount servers in your data center through a single user interface. HP KVM Analog Console Switches utilize a local On-Screen Display (OSD) interface, accessed through a rack console such as the HP LCD8500, that provides intuitive menus for accessing each attached server or serial managed device.
HP G3 KVM Analog Console Switches support an optional USB Remote Access Key that allow you to upgrade to KVM-over-IP functionality, providing remote access and management via the On-Board Web Interface (OBWI). HP KVM Analog Console Switches are available in 4, 8 and 16-Port models.
Standard rack mounting of the KVM Console Switch will share 1U (1.75-inch) of front panel rack space with the rack console. However, each model can also be mounted in a "zero U" profile by mounting in the side rails of the rack.
HP G3 KVM Analog Console Switches support an optional USB Remote Access Key that allow you to upgrade to KVM-over-IP functionality, providing remote access and management via the On-Board Web Interface (OBWI). HP KVM Analog Console Switches are available in 4, 8 and 16-Port models.
Standard rack mounting of the KVM Console Switch will share 1U (1.75-inch) of front panel rack space with the rack console. However, each model can also be mounted in a "zero U" profile by mounting in the side rails of the rack.
Specifications
General Information
Manufacturer:
Hewlett Packard Enterprise
Manufacturer Website Address:
https://www.hpe.com/au/
Brand Name:
HP
Product Name:
0x1x8 G3 KVM Console Switch
Packaged Quantity:
1
Product Type:
KVM Switchbox
Technical Information
Number of Computers Supported:
8
Number of Local Users Supported:
1
Interfaces/Ports
Network (RJ-45):
Yes
USB:
Yes
VGA:
Yes
Number of Network (RJ-45) Ports:
11
Number of USB Ports:
4
Number of VGA Ports:
1
Physical Characteristics
Form Factor:
Rack-mountable
Rack Height:
1U
Height:
43.7 mm
Width:
431.8 mm
Depth:
110.7 mm
Weight (Approximate):
2.04 kg
Miscellaneous
Green Compliant:
Yes
