CISCO Catalyst 2960-24TC 24 Ports Ethernet Switch
Description
Cisco Catalyst 2960-24TC Intelligent Ethernet Switch is a new family of fixed-configuration standalone devices that provide desktop Fast Ethernet and Gigabit Ethernet connectivity, enabling enhanced LAN services for entry-level enterprise, mid-market, and branch office networks. The Catalyst 2960-24TC offers integrated security, including network admission control (NAC), advanced quality of service (QoS), and resiliency to deliver intelligent services for the network edge.
Specifications
General Information
Manufacturer:
Cisco Systems, Inc
Manufacturer Website Address:
http://www.cisco.com/c/en_au
Brand Name:
Cisco
Product Family:
Catalyst
Product Series:
2960
Product Model:
2960-24TC
Product Name:
Catalyst 2960-24TC Managed Ethernet Switch
Product Type:
Ethernet Switch
Interfaces/Ports
Total Number of Network Ports:
24
Uplink Port:
Yes
Number of Network (RJ-45) Ports:
24
Port/Expansion Slot Details:
- 2 x Gigabit Ethernet Uplink
- 24 x Fast Ethernet Network
Media & Performance
Media Type Supported:
- Twisted Pair
Twisted Pair Cable Standard:
- Category 5
Ethernet Technology:
- Gigabit Ethernet
- Fast Ethernet
Network Technology:
- 100/1000Base-T
I/O Expansions
Number of Total Expansion Slots:
2
Expansion Slot Type:
- SFP
Shared SFP Slot:
Yes
Number of SFP Slots:
2
Network & Communication
Layer Supported:
2
Management & Protocols
Management:
- Telnet
- Syslog
- Web browser
- CiscoWorks
- Remote SPAN
- SNMP v1, v2c, and v3
- Command-line interface
- Cisco Network Assistant
- Switching Database Manager
- Cisco Service Assurance Agent
- IEEE 802.1p CoS
- IEEE 802.1Q VLAN
- RMON groups (history, statistics, alarms, and events)
Memory
Standard Memory:
- 64 MB
Memory Technology:
DRAM
Flash Memory:
32 MB
Power Description
Input Voltage:
- 110 V AC
- 220 V AC
Power Source:
- Power Supply
Redundant Power Supply:
Yes
Physical Characteristics
Height:
43.9 mm
Width:
444.5 mm
Depth:
236.2 mm
Weight (Approximate):
3.60 kg
Miscellaneous
Additional Information:
- LAN Base Image installed
- Entry-level enterprise-class intelligent services
