HPE HP MSR3024 Router - 1U

HPE HP MSR3024 Router - 1U
JG407A

This product has been discontinued by the manufacturer

Please visit

HPE Routers & Gateways

for alternative options.

Description

The HP MSR3000 Router Series, the next generation of router from HP, is a component of the HP FlexBranch solution, which is a part of the comprehensive HP FlexNetwork architecture. These routers feature a modular design that delivers unmatched application services for medium- to large-sized branch offices. This gives your IT personnel the benefit of reduced complexity, and simplified configuration, deployment, and management.

The MSR3000 routers use the latest multicore CPUs, offer Gigabit switching, provide an enhanced PCI bus, and ship with the latest version of HP Comware software to help ensure high performance with concurrent services. The MSR3000 series provides a full-featured, resilient routing platform, including IPv6 and MPLS, with up to 5 Mpps forwarding capacity and 3.3 Gb/s of IPSec VPN encrypted throughput. These routers also support HP Open Application Platform (OAP) modules to deliver integrated industry-leading HP AllianceOne partner applications such as virtualization, unified communications and collaboration (UC&C), and application optimization capabilities.

Specifications

General Information

Manufacturer:
Hewlett Packard Enterprise
Manufacturer Website Address:
https://www.hpe.com/au/
Brand Name:
HP
Product Series:
MSR3000
Product Model:
MSR3024
Product Name:
MSR3024 DC Router
Product Type:
Router

Interfaces/Ports

Total Number of Ports:
3
USB:
Yes
Powerline:
No
Management Port:
Yes
Token Ring Port:
No
Serial V.35 Interface:
No
Number of Broadband (RJ-45) Ports:
3

I/O Expansions

Number of Total Expansion Slots:
8
Expansion Slot Type:
  • Smart Interface Card (SIC)
  • SFP (mini-GBIC)
  • High-performance Multifunction Interface Module (HMIM)
  • Voice Processing Module

Network & Communication

Network Technology:
  • 10/100/1000Base-T
Ethernet Technology:
  • Gigabit Ethernet

Management & Protocols

Security Features:
  • IEEE 802.1X
  • RFC 2104 Keyed-Hashing for Message Authentication
  • IKE
  • Access Control List
  • EAP
  • TLS
  • RADIUS
  • Firewall
  • NAT
  • IPSec
  • TACACS+
  • AAA
  • DES
  • 3DES
  • AES 128/192/256-bit
  • SHA-1
  • MD5

Memory

Standard Memory:
  • 2 GB
Memory Technology:
DDR3 SDRAM
Flash Memory:
256 MB
Memory Card Supported:
  • CompactFlash

Power Description

PoE Port:
No
Power Source:
  • AC Adapter

Physical Characteristics

Compatible Rack Unit:
1U
Form Factor:
  • Rack-mountable
  • Desktop
Height:
44.2 mm
Width:
439.9 mm
Depth:
480.1 mm
Weight (Approximate):
7.32 kg
