HPE HP MSR1003-8 Router Chassis - 19U

HPE HP MSR1003-8 Router Chassis - 19U
JG732A
Please Call
Please contact us for pricing

Description

The HP MSR1000 router series is a next generation multi-services router designed to deliver unmatched application performance for small sized branch offices. The MSR1000 provides a flexible multiservice end point for small branch/office or departmental end points that quickly adapts to changing business requirements while delivering integrated, concurrent services on a single, easy-to-manage platform.
  • Up to 500Kpps IP forwarding; converged high-performance routing
  • Embedded security features with hardware-based encryption, firewall, NAT, and VPNs
  • Industry-leading breadth of LAN and WAN connectivity options
  • No additional licensing complexity; no cost for advanced features
  • Zero-touch solution, with single-pane-of-glass management

Specifications

General Information

Manufacturer:
Hewlett Packard Enterprise
Manufacturer Website Address:
https://www.hpe.com/au/
Brand Name:
HP
Product Series:
MSR1000
Product Model:
MSR1003-8
Product Name:
MSR1003-8 AC Router Chassis
Product Type:
Router Chassis

Interfaces/Ports

Total Number of Ports:
10
USB:
Yes
Powerline:
No
Management Port:
Yes
Token Ring Port:
No
Serial V.35 Interface:
No
Number of Network (RJ-45) Ports:
8
Number of Broadband (RJ-45) Ports:
2

I/O Expansions

Number of Total Expansion Slots:
3
Expansion Slot Type:
  • Smart Interface Card (SIC)

Network & Communication

Network Technology:
  • 10/100/1000Base-T
Ethernet Technology:
  • Gigabit Ethernet
VoIP Supported:
Yes

Management & Protocols

Security Features:
  • ACL
  • TACACS+
  • IEEE 802.1x
  • RADIUS
  • NAT
  • SSHv2
  • IPSec
  • DES
  • 3DES
  • 128/192/256-bit AES
  • MD5
  • SHA-1
  • DVPN
  • VPN Firewall
  • Web Filtering
  • SPI

Memory

Standard Memory:
  • 512 MB
Memory Technology:
DDR3 SDRAM
Flash Memory:
256 MB
Memory Card Supported:
  • CompactFlash

Power Description

PoE Port:
No
Input Voltage:
  • 110 V AC
  • 220 V AC
Power Source:
  • Power Supply

Physical Characteristics

Compatible Rack Unit:
19U
Form Factor:
  • Rack-mountable
  • Desktop
Height:
41.9 mm
Width:
359.9 mm
Depth:
300 mm
Weight (Approximate):
4.85 kg

Miscellaneous

Certifications & Standards:
Emissions:
  • EN 55022 Class B
  • ICES-003 Class B
  • ANSI C63.4 2003
  • ETSI EN 300 386 V1.3.3
  • EN 61000-4-2
  • EN 61000-4-3
  • EN 61000-4-4
  • EN 61000-4-5
  • EN 61000-4-6
  • EN 61000-3-2:2006
  • EN 61000-3-3:1995 +A1:2001+A2:2005
  • EMC Directive 2004/108/EC
  • EN 55024:1998+ A1:2001 + A2:2003
  • EN 61000-4-11:2004
  • EN 61000-4-8:2001
  • AS/NZS CISPR 22 Class B
  • FCC (CFR 47, Part 15) Class B
Telecom:
  • FCC part 68
  • CS-03
IEEE Standards:
  • 802.1p
  • 802.1d
Green Compliant:
Yes
