CISCO ONS-XC-10G-S1= XFP - 1 x OC-192/STM-64
Description
The 10 Gbps 1310 nm XFP transceiver is an integrated fiber optic transceiver that provides a high-speed serial link. The XFP integrates the receiver and transmit path. The transmit side recovers and retimes the 10 Gbps serial data and passes it to a laser driver. The receive side recovers and retimes the 10 Gbps optical data stream from a PIN photo detector, transimpedance amplifier and passes it to an output driver.
Specifications
General Information
Manufacturer:
Cisco Systems, Inc
Manufacturer Website Address:
http://www.cisco.com/c/en_au
Brand Name:
Cisco
Product Model:
ONS-XC-10G-S1=
Product Name:
10 Gbps OC-192/STM-64 XFP Module
Product Type:
XFP
Technical Information
Application/Usage:
- Data Networking
Interfaces/Ports
Interfaces/Ports:
- 1 x OC-192/STM-64
Interfaces/Ports Details:
- 1 x LC Duplex OC-192/STM-64
Media & Performance
Connectivity Media:
- Single-mode Optical Fiber
Distance Supported:
- 2 km to 10 km Single-mode Optical Fiber
Data Transfer Rate:
- 10 Gbps OC-192/STM-64
- 10 Gbps Fibre Channel
- 10 Gbps Gigabit Ethernet
Physical Characteristics
Form Factor:
Hot-swappable
Dimensions:
8.4 mm Height x 18.3 mm Width x 78.7 mm Depth
Miscellaneous
Additional Information:
- Spare Product
- Wavelength: 1310 nm
- 10 km (6.2 miles) for 10GE/10GFC
- 2 km (1.2 miles) for OC-192/STM64
Compatibility:
ONS 15454 SONET/SDH
