STARTECH Signal Splitter - Plastic

STARTECH .com Signal Splitter - Plastic
Retail price: $274.99
$272.25
(Includes GST) You save: $2.74 (1%) Save 1%
MSTDP123DP
Available
+
Add to favourites

Description

Use this multi-stream transport hub to connect three DP monitors to a single DP 1.2 port. This MST hub lets you connect three monitors to your DisplayPort™ (DP) 1.2 equipped Windows® laptop or desktop.

Increase productivity with multiple screens

The newest generations of computers are more portable than ever, which often means that you're left with fewer video outputs and smaller integrated screens. This MST hub solves both of these problems by letting you connect three additional displays to your computer, which makes multitasking much easier.



Connect to any display

With the MST hub, you can use DisplayPort video adapters and cable adapters that enable you to connect HDMI, VGA or DVI displays. This ensures your MST hub will be compatible with virtually any television, monitor or projector. This MST hub is VESA and DisplayPort certified to support DP 1.2 enabled systems, for seamless integration with your existing video equipment.



Configure your displays for any environment

Using the MST hub, you can extend your desktop onto additional monitors and stream independent content to each display giving you the freedom to multitask and increase your productivity. You can also mirror the same image onto multiple displays for remote viewing applications such as digital signage.





Enjoy amazing video quality, without draining system resources

MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. This unprecedented performance makes MST perfect for high-resolution applications such as graphic design, gaming and medical imaging.

Note: When using a DisplayPort 1.1 video card the MSTDP123DP will act as splitter, automatically mirroring your video source across all displays. Resolution limitations apply.

The MSTDP123DP supports plug-and-play installation for a hassle-free setup, and is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup. Certain graphics adapters have limited MST support and will only output to three displays in total. If more than three monitors are attached the fourth will be disabled.

Specifications

General Information

Manufacturer:
StarTech.com
Manufacturer Website Address:
http://www.startech.com/au
Brand Name:
StarTech.com
Product Name:
MST hub - DisplayPort to 3x DisplayPort
Packaged Quantity:
1
Product Type:
Signal Splitter

Interfaces/Ports

DisplayPort:
Yes
Number of DisplayPort Inputs:
1
Number of DisplayPort Outputs:
3

Physical Characteristics

Colour:
  • Black
Material:
Plastic
Height:
20.3 mm
Width:
78.7 mm
Length:
200.7 mm
Weight (Approximate):
95 g

Miscellaneous

Package Contents:
  • Triple Head DisplayPort 1.2 Multi Monitor MST Hub
  • 1 x Power Adapter
  • 1 x Instruction Manual
Additional Information:
    • Input Current 0.5 A
    • Output Voltage 5 DC
    • Output Current 3A
    • Center Tip Polarity Positive
    • Maximum Digital Resolutions Up to 4K
    • Wide Screen Supported Yes
Certifications & Standards:
  • CE
  • FCC
Green Compliant:
Yes
Green Compliance Certificate/Authority:
  • RoHS

Warranty

Standard Warranty:
2 Year
