STARTECH .com Signal Splitter

STARTECH .com Signal Splitter
Retail price: $178.19
$176.50
(Includes GST) You save: $1.69 (1%) Save 1%
MSTCDP122DP
Available
+
Add to favourites

Description

Use this adapter to connect two independent displays to a single USB Type-C port. This MST hub lets you connect two DisplayPort monitors to your USB-C™ computer. MST works on any Windows® device with DP alt mode over USB Type-C™, such as models of Dell Precision™ and Dell XPS™ laptops. The MST hub is powered by the USB-C port, so you don't require an additional power adapter.

This adapter works with USB Type-C devices that pass a DisplayPort video signal and it's also compatible with Thunderbolt™ 3 ports.

Increase your productivity with multiple monitors

The newest generations of laptops are more portable than ever. Unfortunately, this could mean that you're left with fewer video outputs and confined to a small integrated screen. This MST hub solves these problems by letting you connect two independent displays to a USB-C port on your computer, which makes multitasking much easier.

Using the MST hub, you can extend your desktop onto additional monitors and stream independent content to each display. This makes it easier to multitask and increase your productivity -- perfect for creating an easy-to-dock hot-desk solution with a wireless keyboard and mouse peripheral set.

The hub also lets you mirror the same image onto multiple displays, for remote viewing applications such as digital signage.



Astonishing picture quality that won't drain your system resources

MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. 4K is supported by the latest A/V devices and offers four times the resolution of 1080p. Plus, because the MST hub can output high-definition 1080p, the MST hub is perfect for all high-resolution applications such as graphic design and CAD drawing.

Works with any monitor, television or projector

With this MST hub, you can use separate DP video adapters to connect HDMI, VGA or DVI displays, for compatibility with all of your existing monitors. The hub supports DP 1.2 enabled systems, for seamless integration with your existing video equipment.



The MSTCDP122DP supports plug-and-play installation for a hassle-free setup and is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Notes:

Your USB-C equipped device must support video (DP alt mode) to work with this adapter.

MST shares 21.6Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup.

Average resolution bandwidth allocation
1920x1080 (High-definition 1080p) @60hz - 22%
1920x1200 @60hz - 30%
2560x1440 @60hz - 35%
2560x1600 @60hz - 38%
3840 x 2160 (Ultra HD 4K) @30hz - 38%

Exceeding 100% will reduce functionality

Specifications

General Information

Manufacturer:
StarTech.com
Manufacturer Website Address:
http://www.startech.com/au
Brand Name:
StarTech.com
Product Name:
USB-C to DisplayPort Multi-Monitor Splitter - 2-Port MST Hub
Packaged Quantity:
1
Product Type:
Signal Splitter

Interfaces/Ports

DisplayPort:
Yes
USB:
Yes
Number of DisplayPort Outputs:
2

Physical Characteristics

Height:
15.2 mm
Width:
58.4 mm
Length:
61 mm
Weight (Approximate):
45.4 g
