LENOVO System x x3550 M5 8869Q2M 1U Rack Server - 1 x Intel Xeon E5-2667 v4 Octa-core (8 Core) 3.20 GHz - 16 GB Installed TruDDR4 - 12Gb/s SAS, Serial ATA Controller - 0, 1, 5, 10, 50 RAID Levels - 1 x 750 W
This product has been discontinued by the manufacturer
Please visit
LENOVO Serversfor alternative options.
Description
Designed in a compact, versatile 1U rack form factor, the dual-socket Lenovo System x3550 M5 (E5-2600 v4) server fuels almost any workload in the software-defined data center from infrastructure to high-performance computing (HPC) to cloud or big data with leadership security, efficiency, and reliability features. With support for Intel Xeon processor E5-2600 v4 product family and faster, energy-efficient TruDDR4 memory, the System x3550 M5 delivers exceptional performance. Flexible and scalable internal storage configurations include up to 12x 2.5-inch or 4x 3.5-inch drives with a wide selection of drive sizes and types.
This product guide provides essential pre-sales information to understand the structure of the System x3550 M5 offering, its key features and specifications, components and options, and configuration guidelines.
This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the System x3550 M5 and consider its use in IT solutions.
Specifications
General Information
Manufacturer:
Lenovo Group Limited
Manufacturer Website Address:
http://www3.lenovo.com/au/en
Brand Name:
Lenovo
Product Family:
System x
Product Series:
x3550 M5
Product Model:
8869Q2M
Product Name:
System x3550 M5 8869Q2M Server
Product Type:
Server
Processor & Chipset
Number of Processors Supported:
2
Number of Processors Installed:
1
Processor Manufacturer:
Intel
Processor Type:
Xeon
Processor Model:
E5-2667 v4
Processor Core:
Octa-core (8 Core)
Processor Speed:
3.20 GHz
Memory
Standard Memory:
- 16 GB
Memory Technology:
TruDDR4
Storage
Total Hard Drive Capacity:
No
Controllers
Controller Type:
- 12Gb/s SAS
- Serial ATA
RAID Supported:
Yes
RAID Levels:
- 0, 1, 5, 10, 50
Display & Graphics
Graphics Controller Manufacturer:
- Matrox
Graphics Controller Model:
- G200eR2
Graphics Memory Capacity:
- Up to 16 MB
Network & Communication
Ethernet Technology:
- Gigabit Ethernet
Software
Operating System:
No
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Number of Power Supplies Installed:
1
Maximum Power Supply Wattage:
750 W
Miscellaneous
Package Contents:
- System x3550 M5 8869Q2M Server
- Statement of Limited Warranty
- Important Notices
- Rack Installation Instructions
- Documentation CD containing Installation and User's Guide
- System x3550 M5 non-ball bearing slide
- LCD Panel
Green Compliant:
Yes
Green Compliance Certificate/Authority:
- RoHS
Physical Characteristics
Form Factor:
Rack
Rack Height:
1U
Height:
43.2 mm
Width:
434.3 mm
Depth:
734.1 mm
Weight (Approximate):
19.30 kg
Warranty
Standard Warranty:
3 Year
