HPE HP ProLiant DL560 G10 2U Rack Server - 4 x Intel Xeon Gold 6148 Icosa-core (20 Core) 2.40 GHz - 128 GB Installed DDR4 SDRAM - 12Gb/s SAS Controller - 2 x 1.60 kW

HPE HP ProLiant DL560 G10 2U Rack Server - 4 x Intel Xeon Gold 6148 Icosa-core (20 Core) 2.40 GHz - 128 GB Installed DDR4 SDRAM - 12Gb/s SAS Controller - 2 x 1.60 kW
840370-B21

This product has been discontinued by the manufacturer

Please visit

HPE Servers

for alternative options.

Description

The HPE ProLiant DL560 Gen10 Server is a high-density, four-socket (4S) server with high performance, scalability and reliability, all in a 2U chassis. Supporting the latest Intel® Xeon® Scalable processors, the HPE ProLiant DL560 Gen10 Server offers greater processing power, up to 3 TB of faster memory, IO of up to eight PCIe 3.0 slots, plus the intelligence and simplicity of automated management with HPE OneView and HPE iLO 5.

The HPE ProLiant DL560 Gen10 Server is the ideal server for business critical workloads, virtualization, server consolidation, database, business processing, and general 4P data-intensive applications where data center space and the right performance are paramount.

Specifications

General Information

Manufacturer:
Hewlett Packard Enterprise
Manufacturer Website Address:
https://www.hpe.com/au/
Brand Name:
HP
Product Family:
ProLiant
Product Series:
DL560 G10
Product Name:
ProLiant DL560 G10 Server
Product Type:
Server

Processor & Chipset

Number of Processors Supported:
4
Number of Processors Installed:
4
Processor Manufacturer:
Intel
Processor Type:
Xeon Gold
Processor Model:
6148
Processor Core:
Icosa-core (20 Core)
Processor Speed:
2.40 GHz

Memory

Standard Memory:
  • 128 GB
Maximum Memory:
1.50 TB
Memory Technology:
DDR4 SDRAM
Number of Total Memory Slots:
48

Storage

Total Hard Drive Capacity:
No

Controllers

Controller Type:
  • 12Gb/s SAS
RAID Supported:
Yes

I/O Expansions

Number of Total Expansion Bays:
8
Number of Internal 2.5" Bays:
8

Network & Communication

Ethernet Technology:
  • 10 Gigabit Ethernet

Software

Operating System:
No

Power Description

Input Voltage:
  • 120 V AC
  • 230 V AC
Number of Power Supplies Installed:
2
Maximum Power Supply Wattage:
1.60 kW
Redundant Power Supply:
Yes

Miscellaneous

Green Compliant:
Yes

Physical Characteristics

Form Factor:
Rack
Rack Height:
2U
Height:
87.4 mm
Width:
445.5 mm
Depth:
754.6 mm
Weight (Approximate):
34.12 kg
