ASUS PRIME H270-PRO Desktop Motherboard - Intel H270 Chipset - Socket H4 LGA-1151

ASUS PRIME H270-PRO Desktop Motherboard - Intel H270 Chipset - Socket H4 LGA-1151
PRIME H270-PRO

This product has been discontinued by the manufacturer

Please visit

ASUS Motherboards

for alternative options.

Description

Ready for 7th generation Intel® Core™ processors, the Prime H270-PRO delivers customizable performance. 5X Protection III with FanXpert 4 Core provides hardware-level safeguards. CrossFireX drives support for Multiple GPUs, while Dual M.2 slots and USB 3.1 deliver maximum transfer speeds. Create your unique build with 3D printing mounts.

Specifications

General Information

Manufacturer:
ASUS Computer International
Manufacturer Website Address:
http://www.asus.com/au
Brand Name:
Asus
Product Model:
PRIME H270-PRO
Product Name:
PRIME H270-PRO Desktop Motherboard
Product Type:
Desktop Motherboard

Processor & Chipset

Chipset Manufacturer:
Intel
Chipset Model:
H270
Total Processor Supported:
1
Processor Socket:
Socket H4 LGA-1151
Processor Supported:
  • Core i7
  • Core i5
  • Core i3
  • Pentium
  • Celeron
Multi GPU Supported:
  • CrossFireX

Memory

Number of Memory Slots:
4
Maximum Memory:
64 GB
Memory Technology:
DDR4 SDRAM

I/O Controller

Controller Type:
  • Serial ATA/600
RAID Supported:
Yes
RAID Levels:
  • 0
  • 1
  • 5
  • 10

Video

Onboard Video:
CPU Dependent Video

Audio

Audio Channels:
7.1

Network & Communication

Gigabit Ethernet:
Yes
Wi-Fi:
No

I/O Expansions

Number of Total Expansion Slots:
6
Total Number of PCI Express Slots:
6
Number of PCI Express x1 Slots:
2
Number of PCI Express x4 Slots:
0
Number of PCI Express x16 Slots:
2

Interfaces/Ports

Number of eSATA Ports:
0
Total Number of USB Ports:
5
Number of USB 3.0 Ports:
3
Number of USB 3.1 Ports:
2
S/PDIF:
No
HDMI:
Yes
DisplayPort:
Yes
DVI:
Yes

Onboard Interfaces

Number of SATA Interfaces:
6
Number of M.2 Interfaces:
2
Onboard S/PDIF Header:
Yes

Physical Characteristics

Form Factor:
ATX
