HP BladeSystem BLc7000 Blade Server Case - Rack-mountable - 120.20 kg

681840-B21

This product has been discontinued by the manufacturer

Please visit

HP Computer Casings

for alternative options.

Description

The BladeSystem c7000 enclosure provides all the power, cooling, and I/O infrastructure needed to support modular server, interconnect, and storage components today and throughout the next several years. The enclosure is 10U high and holds up to 16 server and/or storage blades plus optional redundant network and storage interconnect modules.

It includes a shared, 5 Tbps high-speed NonStop mid-plane for wire-once connectivity of server blades to network and shared storage. Power is delivered through a pooled-power backplane, and power input flexibility is provided with choices of single-phase, 3-Phase AC input, and -48V DC input.

Specifications

General Information

Manufacturer:
Hewlett-Packard
Manufacturer Website Address:
http://www.hp.com/au/
Brand Name:
HP
Product Family:
BladeSystem
Product Model:
BLc7000
Product Name:
BLc7000 Platinum Enclosure w/1 Phase 2 Pwr Supplies 4 Fans ROHS Trial IC Lic
Product Type:
Blade Server Case

Technical Information

Number of Fans Supported:
10
Number of Fans Installed:
4

Bays

Number of Total Expansion Bays:
16

Power Description

Input Voltage:
  • 110 V AC
  • 220 V AC
Number of Power Supplies Supported:
6
Number of Power Supplies Installed:
2
Power Supply Wattage:
2.40 kW
Redundant Power Supply:
Yes

Physical Characteristics

Form Factor:
Rack-mountable
Height:
1012.9 mm
Width:
758.9 mm
Depth:
606.5 mm
Weight (Approximate):
120.20 kg
