LENOVO ThinkPad Helix 36981A4 Ultrabook/Tablet - 29.5 cm (11.6") - Intel Core i5 i5-3337U 1.80 GHz - Black - 4 GB RAM - 256 GB SSD - Genuine Windows 8 64-bit - Convertible - 1920 x 1080 Multi-touch Screen Display (LED Backlight)

LENOVO ThinkPad Helix (3698-1A4) 36981A4
36981A4

This product has been discontinued by the manufacturer

Please visit

LENOVO Tablets & Tablet PCs

for alternative options.

Description

The new ultrabook convertible defines the next generation of mobile computing through its ground breaking "rip and flip" design. This special design gives users absolute mobile freedom and versatility with four unique ways to use it. It's an ultra flexible machine with four usage modes - laptop mode, stand mode, tablet mode and tablet+ mode.

Specifications

General Information

Manufacturer Website Address:
http://www3.lenovo.com/au/en
Product Family:
ThinkPad Helix
Product Model:
36981A4
Product Name:
-
Product Type:
Ultrabook/Tablet

Processor & Chipset

Processor Manufacturer:
Intel
Processor Type:
Core i5
Processor Model:
i5-3337U
Processor Speed:
1.80 GHz
Processor Core:
Dual-core (2 Core)
Cache:
3 MB
Direct Media Interface:
5 GT/s
64-bit Processing:
Yes
Hyper-Threading:
Yes
vPro Technology:
No
Chipset Manufacturer:
Intel
Chipset Model:
QS77 Express

Memory

Standard Memory:
  • 4 GB
Memory Technology:
Memory Standard:

Storage

Solid State Drive Capacity:
256 GB
Solid State Drive Interface:
mini-SATA

Display & Graphics

Screen Size:
29.5 cm (11.6")
Display Screen Type:
Active Matrix TFT Colour LCD
Display Screen Technology:
  • In-plane Switching (IPS) Technology
Aspect Ratio:
16:9
Screen Mode:
Full HD
Screen Resolution:
1920 x 1080
Backlight Technology:
LED
Touchscreen:
Yes
Multi-touch Screen:
Yes
Graphics Controller Manufacturer:
  • Intel
Graphics Controller Model:
  • HD 4000
Graphics Memory Technology:
Graphics Memory Accessibility:
  • Shared

Network & Communication

Wi-Fi:
Yes
Wi-Fi Manufacturer:
Intel
Wi-Fi Model:
Centrino Advanced-N 6205S
Wi-Fi Standard:
  • IEEE 802.11a/b/g/n

I/O Expansions

Expansion Slot Type:
  • SIM Card
  • Mini PCI Express

Interfaces/Ports

Total Number of USB Ports:
3
Number of USB 2.0 Ports:
1
Number of USB 3.0 Ports:
2
Network (RJ-45):
No
DisplayPort:
Yes
Headphone/Microphone Combo Port:
Yes

Input Devices

Keyboard Type:
Physical Keyboard
Keyboard:
Yes
Pointing Device Type:
  • TouchPad
  • Trackpoint
TouchPad Features:
Multi-touch Gesture

Built-in Devices

Sensor Type:
  • Ambient Light Sensor
  • Accelerometer
  • Digital Compass
Front Camera/Webcam:
Yes
Front Camera Resolution/Webcam Resolution:
2 Megapixel
Rear Camera:
Yes
Rear Camera Resolution:
5 Megapixel
Rear Camera Video Resolution:
1920 x 1080
Focus Modes:
  • Fixed Focus
  • Auto-focus
Microphone:
Yes
Speakers:
Yes

Software

Operating System Platform:
Windows
Operating System:
Genuine Windows 8
Operating System Architecture:
64-bit

Battery Information

Number of Batteries Supported:
2
Number of Cells:
4-cell
Battery Chemistry:
Lithium Polymer (Li-Polymer)
Battery Energy:
  • 42 Wh
  • 28 Wh
Maximum Battery Run Time:
8 Hour

Power Description

Maximum Power Supply Wattage:
45 W

Physical Characteristics

Colour:
  • Black
Form Factor:
Convertible
Height:
20.3 mm
Width:
296.2 mm
Depth:
226.1 mm
Weight (Approximate):
1.61 kg

Miscellaneous

Package Contents:
  • ThinkPad Helix (3698-1A4)
  • AC Adapter
Features:
  • Gorilla Glass
Security Features:
Green Compliant:
Yes
Green Compliance Certificate/Authority:
  • Energy Star 5.0
  • RoHS
