HP ProLiant MicroServer Gen8 Ultra Micro Tower Server - 1 x Intel Xeon E3-1220L v2 2.30 GHz - 1 Processor Support - 4 GB Standard/16 GB Maximum RAM - Serial ATA/600 RAID Supported Controller - Gigabit Ethernet - RAID Level: 0, 1, 1+0 - 150 W

HP ProLiant MicroServer Gen8 E3-1220Lv2 1P 4GB- U B120i NHP SATA 150W PS Server G0M45A
G0M45A

This product has been discontinued by the manufacturer

Please visit

HP Servers

for alternative options.

Description

HP ProLiant MicroServer Gen8 is a small, quiet, and stylishly designed server that is ideal for micro and small businesses looking to build their first IT server environment. With a form factor that is easy to use and service, HP MicroServer Gen8 helps businesses get to a server that provides better and secured access to data, more efficiency in operations, while driving down their operating expenses.

Specifications

General Information

Manufacturer:
Hewlett-Packard
Manufacturer Website Address:
http://www.hp.com/au/
Brand Name:
HP
Product Family:
ProLiant
Product Series:
MicroServer Gen8
Product Name:
ProLiant MicroServer Gen8 E3-1220Lv2 1P 4GB- U B120i NHP SATA 150W PS Server
Product Type:
Server

Processor & Chipset

Number of Processors Supported:
1
Number of Processors Installed:
1
Processor Manufacturer:
Intel
Processor Type:
Xeon
Processor Model:
E3-1220L v2
Processor Core:
Dual-core (2 Core)
Processor Speed:
2.30 GHz
Maximum Turbo Speed:
3.50 GHz
Cache:
3 MB
Direct Media Interface:
5 GT/s
64-bit Processing:
Yes
Hyper-Threading:
Yes
Chipset Manufacturer:
Intel
Chipset Model:
C204

Memory

Standard Memory:
  • 4 GB
Maximum Memory:
16 GB
Memory Technology:
DDR3 SDRAM
Memory Standard:
  • DDR3-1600/PC3-12800
Number of Total Memory Slots:
2
Memory Card Reader:
Yes
Memory Card Supported:
  • microSD

Storage

Number of Hard Drives:
No
Optical Drive Type:
DVD-Writer

Controllers

Controller Type:
  • Serial ATA/600
RAID Supported:
Yes
RAID Levels:
  • 0, 1, 1+0

I/O Expansions

Number of Total Expansion Bays:
5
Number of External 5.25" Bays:
1
Number of 3.5" Bays:
4
Number of Total Expansion Slots:
1
Number of PCI Express x16 Slots:
1

Display & Graphics

Graphics Controller Manufacturer:
  • Matrox
Graphics Controller Model:
  • G200

Network & Communication

Ethernet Technology:
  • Gigabit Ethernet

Interfaces/Ports

Total Number of USB Ports:
7
Number of USB 2.0 Ports:
5
Number of USB 3.0 Ports:
2
Network (RJ-45):
Yes
Remote Management:
Yes

Software

Operating System:
No

Power Description

Input Voltage:
  • 120 V AC
  • 230 V AC
Number of Power Supplies Installed:
1
Maximum Power Supply Wattage:
150 W

Miscellaneous

Package Contents:
  • ProLiant MicroServer Gen8 G2020T 1P 4GB-U B120i NHP SATA 1TB 150W PS Svr/S-Buy
  • 6' Country Specific NEMA Power Cord
Compatibility:
  • Microsoft Windows Server
  • Red Hat Enterprise Linux (RHEL)
  • SUSE Linux Enterprise Server (SLES)
  • VMware
Certifications & Standards:
  • ACPI V2.0b Compliant
  • PCIe 2.0 Compliant
  • PXE Support
  • WOL Support
  • FCC Rating Class B
  • CISPR 22
  • EN55022
  • EN55024
  • FCC CFR 47, Pt 15
  • ICES-003
  • CNS13438
  • GB9254
  • K22
  • K24
  • EN 61000-3-2
  • EN 61000-3-3
  • EN 60950-1
  • IEC 60950-1
Green Compliant:
Yes
Green Compliance Certificate/Authority:
  • WEEE
  • EU WEEE

Physical Characteristics

Form Factor:
Ultra Micro Tower
Height:
232.4 mm
Width:
230 mm
Depth:
245 mm
Weight (Approximate):
9.80 kg

Warranty

Standard Warranty:
1 Year
