LENOVO ThinkCentre 3209N6M Desktop Computer - Intel Core i5 i5-3470 3.20 GHz - Small Form Factor - Business Black - 4 GB RAM - 500 GB HDD - DVD-Writer - RAID Supported - Intel HD 2500 Graphics - Genuine Windows 7 Professional - DisplayPort

3209N6M

This product has been discontinued by the manufacturer

Please visit

LENOVO Desktop Computers

for alternative options.

Description

A new era of performance and manageabilityThinkCentre M Series continues to expand cost- and management-control capabilities, providing enterprise users and IT managers with smarter ways to be more productive. Our latest models offer improved overall system performance, optimized for the most demanding applications, from video editing to 2D/3D image design and more. Expanded power management compatibilities help you achieve new levels of energy efficiency, while Dual Independent Display (DID) support enables you to view up to four screens simultaneously. Lower costs while improving productivity across your enterprise.

Specifications

General Information

Manufacturer:
Lenovo Group Limited
Manufacturer Website Address:
http://www3.lenovo.com/au/en
Brand Name:
Lenovo
Product Family:
ThinkCentre
Product Series:
M92p
Product Model:
3209N6M
Product Name:
ThinkCentre M92p (3209-N6M)
Product Type:
Desktop Computer

Processor & Chipset

Number of Processors Supported:
1
Number of Processors Installed:
1
Processor Manufacturer:
Intel
Processor Type:
Core i5
Processor Model:
i5-3470
Processor Core:
Quad-core (4 Core)
Processor Speed:
3.20 GHz
Cache:
6 MB
Direct Media Interface:
5 GT/s
64-bit Processing:
Yes
Hyper-Threading:
No
Chipset Manufacturer:
Intel
Chipset Model:
Q77 Express

Memory

Standard Memory:
  • 4 GB
Maximum Memory:
32 GB
Memory Technology:
DDR3 SDRAM
Memory Standard:
  • DDR3-1600/PC3-12800
Number of Total Memory Slots:
4

Storage

Total Hard Drive Capacity:
500 GB
Hard Drive Interface:
Serial ATA/600
Hard Drive RPM:
7200
Optical Drive Type:
DVD-Writer
Optical Media Supported:
DVD-RAM/±R/±RW
Dual-Layer Media Supported:
Yes

Controllers

Controller Type:
  • Serial ATA/600
RAID Supported:
Yes
RAID Levels:
  • 0, 1

Display & Graphics

Graphics Controller Manufacturer:
  • Intel
Graphics Controller Model:
  • HD 2500
Graphics Memory Technology:
  • DDR3 SDRAM
Graphics Memory Accessibility:
  • Shared

Network & Communication

Ethernet Technology:
  • Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays:
3
Number of External 5.25" Bays:
1
Number of 3.5" Bays:
2
Number of Total Expansion Slots:
4
Number of PCI Slots:
2
Number of PCI Express x1 Slots:
1
Number of PCI Express x16 Slots:
1

Input Devices

Keyboard:
Yes
Pointing Device Type:
  • Mouse

Interfaces/Ports

Total Number of USB Ports:
10
Number of USB 2.0 Ports:
6
Number of USB 3.0 Ports:
4
Network (RJ-45):
Yes
Audio Line In:
Yes
Audio Line Out:
Yes
VGA:
Yes
eSATA:
No
DisplayPort:
Yes

Software

Operating System:
Genuine Windows 7 Professional
Operating System Architecture:
64-bit

Power Description

Maximum Power Supply Wattage:
240 W

Physical Characteristics

Colour:
  • Business Black
Form Factor:
Small Form Factor
Height:
99.0 mm
Width:
338.0 mm
Depth:
386.0 mm
Weight (Approximate):
7.50 kg

Miscellaneous

Package Contents:
  • ThinkCentre M92p (3209-N6M)
  • Keyboard
  • Mouse
Green Compliant:
Yes
Green Compliance Certificate/Authority:
  • Energy Star 5.2
  • GREENGUARD
  • RoHS
  • ULE Gold
