QNAP VioStor VS-2004L Network Video Recorder
This product has been discontinued by the manufacturer
Please visit
QNAP Video Processing/Capturing Modulesfor alternative options.
Description
The VS-2004L VioStor NVR is the 2-bay network surveillance system for home and SOHO security applications. The Linux-based system supports 4-channel H.264, MPEG-4, and M-JPEG recording from ONVIF-compliant IP cameras and surveillance devices from AXIS, ACTi, A-MTK, Arecont Vision, AVTECH, Brickcom, Canon, Cisco, CNB, DIGITUS, D-Link, EDIMAX, ELMO, EtroVision, GANZ, Honeywell, iPUX, IPX, IQeye, LevelOne, Linksys, Messoa, MOBOTIX, NAKAYO, Panasonic BB/BL/i-Pro, Pelco, SANYO, SHANY, SONY, TOA, TOSHIBA, TRENDnet, Videosec, VIOSECURE, VIVOTEK, and Y-CAM.
Specifications
General Information
Manufacturer:
QNAP Systems
Manufacturer Website Address:
http://www.qnap.com/en-au
Brand Name:
QNAP
Product Family:
VioStor
Product Model:
VS-2004L
Product Name:
VioStor 4-Channels Network Video Recorder
Product Type:
Network Video Recorder
Technical Information
Functions:
- Audio Capturing
- Video Recording
- Video Conversion
Video Formats:
- AVI
- H.264
- MJPEG
- MPEG-4
Features:
- Picture in Picture
Memory
Standard Memory:
- 256 MB
Memory Technology:
DDR2
Interfaces/Ports
USB:
Yes
USB Standard:
USB 2.0
Physical Characteristics
Form Factor:
External
Height:
166.0 mm
Width:
85.0 mm
Depth:
218.0 mm
Weight (Approximate):
910.0 g
Miscellaneous
Package Contents:VioStor 4-Channels Network Video Recorder Power Cord Adaptor Ethernet Cable CD QIG(Quick Installation Guide) SATA Cable SATA Power Cable Screw Pack
Additional Information:
- Built-in DDNS service
- Host access control
- One-touch-auto-video-backup
- Real-time SMS and email alert
System Requirements:M-JPEG format (up to 4 channels) Pentium 4 CPU 2.4 GHz or above MPEG-4/ H.264/ MxPEG format (up to 4 channels) Dual core CPU 2.0 GHz or above Internet explorer 6.0 or above Network Interface 10/100/1000 Mbps Display Resolution upto 1024 x 768 pixels or above Operating System(s): Windows XP Windows Vista Windows 7
Compatibility:
Hitachi SATA III(6Gb/s) Hard Drive(s): HUA723030ALA640 HDS723030ALA640 (0S03086) HDS723020BLA642 HDS723015BLA642 Seagate SATA III (6Gb/s) Hard Drive(s): ST33000650NS ST33000651AS ST2000DL003 ST32000641AS ST31000524AS WD SATA III (6Gb/s) Hard Drive(s): WD6000HLHX WD2002FAEX WD10EALX WD1002FAEX WD6402AAEX Hitachi SATA I/ SATA II (3Gb/s) Hard Drive(s): HUA722020ALA330 HDE721010SLA330 HDE721075SLA330 HDS721010CLA332 HDT721010SLA360 HDT721075SLA360 HDS721010KLA330 HDS721075KLA330 Samsung SATA I/ SATA II (3Gb/s) Hard Drive(s): HE103UJ HD204UI HD203WI HD154UI HD103SJ HD103UJ HD103UI HD103SI HD753LJ HD642JJ HD502lJ HD502HI Seagate SATA I/ SATA II (3Gb/s) Hard Drive(s): ST32000644NS ST31000524NS ST31000340NS ST3750330NS ST3500514NS ST3500320NS ST32500310NS ST32000542AS ST31500541AS ST31000520AS ST31000528AS ST3750528AS ST3500418AS ST3320418AS ST3250318AS ST3160318AS ST31500341AS ST31000333AS ST31000340AS ST3750330AS ST3750630AS ST3640323AS ST3500320AS ST3500620AS ST3320613AS ST3160813AS WD SATA I/ SATA II (3Gb/s) Hard Drive(s): WD2003FYYS WD2002FYPS WD1003FBYX WD1002FBYS WD5003ABYX WD2001FASS WD10EALS WD7500AAKS WD6400AAKS WD5000AAKS WD5000AAJS WD4000AAKS WD4000AAJS WD3200AAKS WD3200AAJS WD2500AAKS WD1001FALS WD7501AALS WD6401AALS WD5001AALS WD10EVCS WD7500AVCS WD5000AVVS WD10EACS WD7500AACS WD6400AACS WD5000AACS
