ATDEC Telehook TH-3070-UT Wall Mount for Flat Panel Display
Description
The TH-3070-UT is highly durable and extremely strong. This mount supports screens that weigh up to 200 lbs. (91kg) and offers 15 degrees of tilt adjustment which can be set post installation. Very simple to install, the TV is held just 2.75" (72.5mm) from the wall for a display that's streamlined as well as flexible. By adding a padlock your screen is safe and secure thanks to the theft resistant design
Specifications
General Information
Manufacturer:
Atdec Pty Ltd
Manufacturer Website Address:
http://www.atdec.com
Brand Name:
Telehook
Product Model:
TH-3070-UT
Product Name:
TH-3070-UT Wall/Tilt
Product Type:
Wall Mount
Product Information
Device Supported:
- Flat Panel Display
Maximum Load Capacity:
90.72 kg
Minimum Screen Size Supported:
106.7 cm (42")
Maximum Screen Size Supported:
- 203.2 cm (80")
Features:
- Tilt
- Lockable
- Anti-theft
Physical Characteristics
Colour:
- Black
VESA Mount Compatible:
Yes
VESA Mount Standard:
- 800 x 400
- 800 x 200
- 600 x 400
- 400 x 400
- 400 x 300
- 300 x 300
- 300 x 200
- 200 x 200
- 200 x 100
Material:
- Steel
Depth:
76 mm
Miscellaneous
Package Contents:
- Wall Plate
- Security Plate
- Display Bracket (left)
- Display Bracket (right)
- Fasteners
- 4 x Coach Screw
- 4 x Masonry Wall Plug
- 4 x Multi Washer
- 4 x Washer
- 6 x Dry Wall Anchor
- 4 x 13mm Spacer Bush
- 4 x 20mm Spacer Bush
- 4 x (M8x15mm) Cross Recessed Screws
- 4 x (M8x35mm) Cross Recessed Screws
- 4 x (M8x45mm) Cross Recessed Screws
- 4 x (M6x15mm) Cross Recessed Screws
- 4 x (M6x35mm) Cross Recessed Screws
- 4 x (M6x45mm) Cross Recessed Screws
- 4 x (M5x15mm) Cross Recessed Screws
- 4 x (M5x35mm) Cross Recessed Screws
- 4 x (M5x45mm) Cross Recessed Screws
- 4 x (M4x15mm) Cross Recessed Screws
- 4 x (M4x35mm) Cross Recessed Screws
- 4 x (M4x45mm) Cross Recessed Screws
Additional Information:
- Mounting Hole Pattern (mm): From 180-800 Wide x 125-500 high
Compatibility:
- LCD
- LED
- Plasma
Assembly Required:
- Yes
Warranty
Standard Warranty:
10 Year
