ATDEC Telehook TH-1040-CTS Ceiling Mount for Flat Panel Display
Description
This ceiling pole mount is designed for low weight LED/ LCD screens. It provides telescopic height adjustment and supports with pole rotation. It features a Quick Attachment head for easy display attachment / replacement, integrated cable mgmt, and a ball-joint for tilt, pan and screen rotation. It can also be upgraded for dual display support. It ships with an install guide, display and ceiling mounting hardware. A longer pole model TH-1040-CTL is available
Specifications
General Information
Manufacturer:
Atdec Pty Ltd
Manufacturer Website Address:
http://www.atdec.com
Brand Name:
Telehook
Product Model:
TH-1040-CTS
Product Name:
TH-1040-CTS Ceiling Telescopic Short Pole Mount
Product Type:
Ceiling Mount
Product Information
Device Supported:
- Flat Panel Display
Maximum Load Capacity:
24.95 kg
Features:
- Tilt
- Swivel
Physical Characteristics
Colour:
- Black
VESA Mount Compatible:
Yes
VESA Mount Standard:
- 200 x 200
- 200 x 100
- 100 x 100
- 75 x 75
Material:
- Steel
- Plastic
- Aluminium
Miscellaneous
Package Contents:
- 1 x Ceiling Plate
- 2 x Small/Large VESA Plate
- 1 x Ceiling Plate Cover
- 1 x Plate Assembly
- 1 x Tension Tool
- 4 x Coach Screw
- 4 x Nylon Anchor
- 4 x M4 Washer
- 4 x M5 Washer
- 4 x M10 Washer
- 4 x M4 Spacer
- 4 x M5 Spacer
- 4 x M6 Spacer
- Security Screw
- Set Screw
- 1 x 2.5mm Allen Key
- 1 x 3mm Allen Key
- 1 x 5mm Allen Key
- 4 x M4 x 16mm Display Mounting Screws
- 4 x M4 x 25mm Display Mounting Screws
- 4 x M5 x 16mm Display Mounting Screws
- 4 x M5 x 25mm Display Mounting Screws
- 4 x M6 x 16mm Display Mounting Screws
- 4 x M6 x 30mm Display Mounting Screws
Additional Information:
- Telescopic pole adjustment from: 15.75" - 35.43" (400mm to 900mm)
- Secondary display height adjustment of 12.40" (315mm)
- Portrait to landscape rotation
- Secondary display height adjustment of 12.40" (315mm)
- Ball joint mechanism allows for display angular adjustment of 20 degrees in any direction; portrait to landscape rotation
- Quick release mechanism for easy display attachment/removal with security screw for theft resistance
- 360 Degrees around the pole
Compatibility:
- LCD
- LED
Assembly Required:
- Yes
Warranty
Standard Warranty:
10 Year
