CISCO Meraki MR26 IEEE 802.11n 900 Mbps Wireless Access Point - ISM Band - UNII Band - 1 x Network (RJ-45) - Desktop, Wall Mountable
This product has been discontinued by the manufacturer
Please visit
CISCO Wireless Access Points/Bridgesfor alternative options.
Description
High performance cloud-managed wireless LAN
The Cisco Meraki MR26 is an industry-first three-radio, cloud-managed 3x3 MIMO 802.11n access point designed for high-density deployments in large offices, schools, hospitals and hotels that require premium performance. The MR26 features dual-concurrent, dual-band operation with the speed of 3x3 MIMO with three spatial streams, delivering the ultra-high throughput and reliable coverage required by the most demanding business applications like voice and high-definition streaming video. Not only does the MR26 provide data rates of up to 900 Mbps with two concurrent 3x3:3 MIMO radios, but also delivers unprecedented security and spectrum visibility via a third radio dedicated to 24x7 WIDS/WIPS and advanced RF analytics.
The Cisco Meraki MR26 is an industry-first three-radio, cloud-managed 3x3 MIMO 802.11n access point designed for high-density deployments in large offices, schools, hospitals and hotels that require premium performance. The MR26 features dual-concurrent, dual-band operation with the speed of 3x3 MIMO with three spatial streams, delivering the ultra-high throughput and reliable coverage required by the most demanding business applications like voice and high-definition streaming video. Not only does the MR26 provide data rates of up to 900 Mbps with two concurrent 3x3:3 MIMO radios, but also delivers unprecedented security and spectrum visibility via a third radio dedicated to 24x7 WIDS/WIPS and advanced RF analytics.
Specifications
General Information
Manufacturer:
Cisco Systems, Inc
Manufacturer Website Address:
http://www.cisco.com/c/en_au
Brand Name:
Meraki
Product Model:
MR26
Product Name:
MR26 Cloud Managed AP
Product Type:
Wireless Access Point
Technical Information
Wi-Fi Standard:
- IEEE 802.11n
ISM Band:
Yes
UNII Band:
Yes
ISM Minimum Frequency:
2.41 GHz
ISM Maximum Frequency:
2.48 GHz
UNII Minimum Frequency:
5.15 GHz
UNII Maximum Frequency:
5.83 GHz
Antenna Gain:
- 3 dBi
- 5 dBi
Antenna Type:
- Omnidirectional Antenna
Wireless Transmission Speed:
900 Mbps
Wireless Security:
- WEP
- WPA
- WPA2-PSK
- WPA2-Enterprise
- TKIP
- AES
Features:
- Quality of Service (QoS)
- MIMO Technology
Interfaces/Ports
Ethernet Port:
Yes
Fast Ethernet Port:
Yes
Gigabit Ethernet Port:
Yes
10Gigabit Ethernet Port:
No
Number of Network (RJ-45) Ports:
1
Network (RJ-11):
No
PoE Port:
No
VGA:
No
HDMI:
No
Audio Line Out:
No
Serial Port:
No
USB:
No
Powerline:
No
Management Port:
No
Management & Protocols
Management:
- Web based management
Power Description
Input Voltage:
- 12 V DC
Power Source:
- AC Adapter
- PoE
Physical Characteristics
Form Factor:
- Desktop
- Wall Mountable
Height:
33 mm
Width:
149.9 mm
Depth:
208.3 mm
Weight (Approximate):
550 g
Warranty
Standard Warranty:
