HPE Aruba 48 Ports Manageable Ethernet Switch - Refurbished

J9853AR
Please Call
Please contact us for pricing

Description

The HP 2530 Switch Series consists of 16 fully managed L2 edge switches that deliver cost-effective, reliable, secure, and easy-to- use connectivity to business networks. Designed for entry-level to midsize enterprise networks, these Gigabit and Fast Ethernet switches deliver full L2 capabilities with optional Power over Ethernet (PoE), enhanced access security, traffic prioritization, and IPv6 host support.

The HP 2530 Switch Series offers uplink flexibility with either four Gigabit or two 10 Gigabit Ethernet uplinks on some 24- and 48- port models. The Gigabit 24- and 48-port models have either two small form-factor pluggable plus (SFP+) or four small form- factor pluggable (SFP) slots for fiber connectivity. The Fast Ethernet 24- and 48-port models have two SFPs and two RJ-45 Gigabit uplinks. The compact and fan-less 8-port switches offer additional flexibility with two dual-personality ports that can be used as either RJ-45 Gigabit Ethernet or SFP ports. Moreover, the HP 2530 PoE+ Switches are IEEE 802.3af and IEEE 802.3at compliant with up to 30 W per port, making them suitable for voice, video, or wireless deployments with PoE+.

Specifications

General Information

Manufacturer:
Hewlett Packard Enterprise
Manufacturer Website Address:
https://www.hpe.com/au/
Brand Name:
Aruba
Product Series:
2530
Product Name:
2530-48G-PoE+-2SFP+ Switch
Product Condition:
Refurbished
Packaged Quantity:
1
Product Type:
Ethernet Switch

Interfaces/Ports

Total Number of Network Ports:
48
Token Ring Port:
No
LRE Port:
No
Uplink Port:
No
Bypass:
No
Modular:
Yes
Management Port:
Yes
USB:
No
Number of PoE+ Ports:
48
Stack Port:
No
Port/Expansion Slot Details:
  • 48 x Gigabit Ethernet Network
  • 2 x 10 Gigabit Ethernet Expansion Slot

Media & Performance

Media Type Supported:
  • Twisted Pair
  • Optical Fiber
Ethernet Technology:
  • Gigabit Ethernet
  • 10 Gigabit Ethernet
Network Technology:
  • 10/100/1000Base-T
  • 10GBase-X

I/O Expansions

Number of Total Expansion Slots:
2
Expansion Slot Type:
  • SFP+
Shared SFP Slot:
No
Number of SFP+ Slots:
2

Network & Communication

Layer Supported:
2

Management & Protocols

Manageable:
Yes
Management:
    • IMC - Intelligent Management Center
    • Command Line Interface
    • Web Based Management
    • MIB
    • QoS
    • SNMP v1, v2c, v3
    • RMON
    • VLAN
    • DHCP

Memory

Standard Memory:
  • 256 MB
Memory Technology:
DDR3 SDRAM
Flash Memory:
128 MB

Power Description

PoE Port:
No
Input Voltage:
  • 120 V AC
  • 230 V AC
Power Source:
  • Power Supply

Physical Characteristics

Compatible Rack Unit:
1U
Form Factor:
  • Rack-mountable
  • Wall Mountable
Height:
44.5 mm
Width:
443 mm
Depth:
330.2 mm
Weight (Approximate):
4.72 kg

Miscellaneous

Certifications & Standards:
Safety:
  • UL 60950-1
  • CAN/CSA 22.2 No. 60950-1
  • EN 60825
  • IEC 60950-1
  • EN 60950-1
Emissions:
  • FCC Class A
  • EN 55022/CISPR-22 Class A
  • VCCI Class A
Immunity:
  • EN 55024
  • CISPR 24
  • EN 55024
  • CISPR 24
  • IEC 61000-4-2
  • IEC 61000-4-3
  • IEC 61000-4-4
  • IEC 61000-4-5
  • IEC 61000-4-6
  • IEC 61000-4-8
  • IEC 61000-4-11
  • EN 61000-3-2
  • IEC 61000-3-2
  • EN 61000-3-3
  • IEC 61000-3-3
IEEE Standards:
  • 802.3
  • 802.3u
  • 802.3ab
  • 802.3at
