APC Metered PDU

APC Metered PDU
AP8453
Please Call
Please contact us for pricing

Description

The Schneider Electric Rack Po wer Distribution Unit (PDU) distributes power to devices in a rack. The Rack PDU measures the load of the P DU, phase, banks, and each individual outlet. You can access the Rack PDU through Web, Telnet, SNMP, SSH, or StruxureWare interfaces for comprehensive configuration and monitoring functionality. The Network Port Sharing (NPS) feature allows up to four AP8XXX Rack PDUs to be conn ected together within a rack in order to share one IP address.

Specifications

General Information

Manufacturer:
American Power Conversion Corp
Manufacturer Website Address:
http://www.apc.com/au
Brand Name:
APC
Product Family:
Metered
Product Name:
Metered-by-Outlet Rack PDU
Product Type:
PDU

Technical Information

Input Receptacles:
IEC 60309 2P+E
Output Receptacles:
  • 21 x IEC 60320 C13
  • 3 x IEC 60320 C19
Protection Type:
  • Overcurrent Protection
  • Overload Protection

Power Description

Input Voltage:
  • 230 V AC
Output Voltage:
  • 230 V AC
Power Rating:
7.40 kVA
Input Current:
  • 32 A

Management

Management:
    • Web
    • Telnet
    • SNMP
    • SSH
    • StruxureWare

Interfaces/Ports

Serial Port:
Yes
Network (RJ-45):
Yes
USB:
Yes

Physical Characteristics

Colour:
  • Black
Form Factor:
  • Rack-mountable
  • Vertical
Rack Height:
0U
Number of Cord/Cable:
1
Cord Length:
3.05 m
Height:
1829 mm
Width:
56 mm
Depth:
51 mm
Weight (Approximate):
8.21 kg

Miscellaneous

Package Contents:
  • Metered-by-Outlet Rack PDU
  • CAN Port Terminator
  • Installation Guide
  • Rack Mounting Brackets
  • Safety Guide
  • Serial Configuration Cable
Certifications & Standards:
  • EN 55022 Class A
  • EN 55024
  • EN 61000-3-2
  • EN 61000-3-3
  • VDE
  • CE
  • IEC/EN 60950-1
  • LVD
  • EMC
Green Compliant:
Yes
Green Compliance Certificate/Authority:
  • REACH
  • RoHS

Warranty

Standard Warranty:
2 Year
