APC Smart-UPS Line-interactive UPS - 620 VA/390 WTower

SC620I
Available
Please contact us for pricing

Description

APC Smart-UPS protects your data by supplying reliable, network-grade power in either traditional Tower or Rack-optimized form factors for space constrained business critical applications. Award winning APC Smart-UPS is the perfect UPS for protecting business critical fileservers (Intel or UNIX based), minicomputers, network switches and hubs, Point of Sale, retail/bank back office and ATM's. With included PowerChute management software for servers and workstations, IT administrators can provide safe system shutdown and advanced UPS management (All major operating systems supported).

SC Series of UPS are not recommended for HP servers

Specifications

General Information

Manufacturer:
American Power Conversion Corp
Manufacturer Website Address:
http://www.apc.com/au
Brand Name:
APC
Product Family:
Smart-UPS
Product Series:
SC
Product Name:
Smart-UPS SC 620VA
Product Type:
Line-interactive UPS

Technical Information

Plug/Connector Type:
  • IEC 320-C14
Dataline Protection:
RJ-45

Power Description

Load Capacity (VA):
620 VA
Load Capacity (Watt):
390 W
Input Voltage:
  • 220 V AC
Surge Energy Rating:
320 J

Management

Alarm:
  • Configurable Delay
  • Low Battery
  • On Battery
Battery Management:
Intelligent Battery Management

Controls/Indicators

Status Indicators:
  • On Line
  • On Battery
  • Replace Battery
  • Overload

Interfaces/Ports

Serial Port:
Yes

Battery Information

Battery Characteristics:
Spill-proof, Maintenance-free
Battery Chemistry:
Sealed Lead Acid
Backup/Run Time (Full Load):
5.50 Minute
Backup/Run Time (Half Load):
15.70 Minute
Hot Swappable:
Yes

Environmental Conditions

Temperature:
  • 45°C
Thermal Dissipation:
70 BTU/h

Physical Characteristics

Colour:
  • Grey
Height:
177.8 mm
Width:
127 mm
Depth:
381 mm
Form Factor:
Tower
Weight (Approximate):
12.25 kg

Miscellaneous

Package Contents:
  • Smart-UPS SC 620VA
  • CD with software
  • Smart UPS signalling RS-232 cable
  • User Manual
Additional Information:
  • Adjustable voltage sensitivity
  • Adjustable voltage-transfer points
  • Automatic restart of loads after UPS shutdown
  • Automatic self-test
  • Boost and Trim Automatic Voltage Regulation (AVR)
  • Cold-start capable
  • Generator Compatible
  • Predictive failure notification
  • Safety-agency approved

Certifications & Standards:
  • CE
  • EN 50091-1
  • EN 50091-2
  • GOST
  • IEC 60950
  • IRAM
  • PCBC
  • VCCI
  • VDE
  • UL 1449

Warranty

Standard Warranty:
2 Year
