ASUS DSL-AC68U IEEE 802.11ac Ethernet, ADSL2+, VDSL2 Modem/Wireless Router

DSL-AC68U

This product has been discontinued by the manufacturer

Please visit

ASUS Wireless Routers

for alternative options.

Description

  • Dual-purpose wireless router and DSL modem, featuring DSL WAN port and switchable Ethernet WAN/LAN ports in a single space-saving device
  • Compatible with ADSL2/2+, ADSL, VDSL2, fiber and cable services for complete future-proofing
  • Combined maximum data rate of 1900 Mbps allows smooth streaming of 4K/UHD videos, online gaming or other bandwidth-intensive tasks
  • Dual dedicated CPUs for wired and wireless connections to maximize both range and stability
  • AiRadar with universal beamforming optimizes signal strength in any direction to give up to 150%* coverage and is backward compatible with 802.11a/b/g/n clients
  • Multi-purpose USB 3.0 port supports file sharing, printers, 3G/4G dongle sharing and media streaming - with up to 10 times faster data transfer than USB 2.0
  • ASUS AiCloud lets you access, sync, share and stream data from your home network to any internet-connected PC, Android or iOS device
Future-proofed versatility with the world's fastest wireless speeds

The ASUS DSL-AC68U is the world's fastest ADSL/VDSL modem Wi-Fi router, with combined dual-band data rates of up to 1900 Mbps. On the 5GHz band, 802.11ac gives 1300 Mbps wireless data rates, while Broadcom® TurboQAM™ technology super-charges 2.4 GHz 802.11n performance from 450 Mbps to 600 Mbps with compatible devices. Compatible with ADSL2/2+, ADSL, VDSL2, fiber and cable services, the top specification completes future-proofing.

Three external antennas boost coverage to the next level, so you can enjoy lag-free gaming and streaming almost anywhere around the house. ASUS AiRadar with universal beamforming technology enhances the Wi-Fi stability and improves coverage up to 150%*. Most importantly, the universal beamforming not only works on 802.11ac clients, but also 802.11a/b/g/n clients.

Powered by dual dedicated CPUs for wired and wireless connections, the DSL-AC68U eliminates the performance drops that plague other routers with busy networks and maximizes both range and stability. So even on the busiest home networks, HD video streaming is always smooth, the latency low for online gaming and VoIP calls, and file downloads are never interrupted.

The easy-to-use ASUSWRT graphical user interface unlocks the power of the DSL-AC68U giving robust control to optimize your network for you. 30-second set-up and easy traffic management means even network newbies can enjoy its sophisticated features, while power users will love its IPv6 support, multiple wireless SSIDs and secure VPN access.

One device, two functions

With a choice of DSL or Ethernet WAN connections, DSL-AC68U can be used a DSL modem plus wireless router, or as a standalone wireless router. You can choose the mode to suit your needs, saving energy and clutter by replacing two separate power-hungry devices. Whether for a basic home setup or an advanced wireless network, DSL-AC68U has all the flexibility you need. You can also let two modes work simultaneously and manage them with ASUSWRT dual WAN function.

Works with any kind of internet connection

Works with any kind of internet connection DSL-AC68U supports all common types of DSL connection, including ADSL2, ADSL2+, ADSL and VDSL2. Thanks to its Ethernet WAN option, it can also be used seamlessly with any fiber or cable-based modem with an Ethernet connection. This makes it ideal for those who intend to upgrade their ISP in the future.

Specifications

General Information

Manufacturer:
ASUS Computer International
Manufacturer Website Address:
http://www.asus.com/au
Brand Name:
Asus
Product Model:
DSL-AC68U
Product Name:
Dual-Band Wireless-AC1900 Gigabit ADSL/VDSL Modem Router
Product Type:
Modem/Wireless Router

Wireless Specifications

Broadband Transmission Technology:
  • Ethernet
  • ADSL2+
  • VDSL2
Wi-Fi Standard:
  • IEEE 802.11ac
ISM Band:
Yes
UNII Band:
Yes
ISM Maximum Frequency:
2.40 GHz
UNII Maximum Frequency:
5 GHz
Total Number of Antennas:
3
Number of External Antennas:
3
Wireless Transmission Speed:
1900 Mbit/s

Interfaces/Ports

Number of Network (RJ-45) Ports:
4
USB:
Yes
PoE Port:
No

Network & Communication

Ethernet Technology:
  • Gigabit Ethernet
VPN Supported:
Yes

Physical Characteristics

Form Factor:
Desktop
Height:
160 mm
Width:
220 mm
Depth:
83.3 mm
Weight (Approximate):
640 g

Miscellaneous

Green Compliant:
Yes
